FKM62.40A.A3.000 Fagor AC Servo Motor
$2,930.27
FKM62.40A.A3.000.11 Fagor AC servo motor, 4,000 RPM rated speed, 400 V AC, 1,024 line Multi-turn absolute sinusoidal 1Vpp encoder, with keyway (half-key blancing), without holding brake.
CNC Router Services Tip
FKM model numbers that end in .11 are updated versions of the original model number. These models are a direct replacement for the original motor.
Servo Motor Lead Time & Availability
Servo motor lead time and availability varies. We recommend keeping a spare servo motor on the shelf to avoid costly downtime.
Product Description
FKM62.40A.A3.000.11 Fagor AC servo motor. 4,000 RPM rated speed, 400 V AC, 1,024 line Multi-turn absolute sinusoidal 1Vpp encoder, with keyway (half-key blancing), without holding brake.
Additional Information
| Brand | FAGOR, Fagor Automation |
|---|---|
| Stall torque | 8.9 N·m |
| Condition | New |
| Rated torque | 6.7 N·m |
| Rated Speed | 4,000 RPM |
| Stall current | 9.3 A |
| Voltage | 400 V AC |
| Calculated Power | 3.7 kW |
| Encoder | Multi-turn absolute sinusoidal 1Vpp encoder, taper shaft, 1024 Count |
| Rated Power | 2.8 kW |
| Manufacturer Part Number | FKM62.40A.A3.000.11 |
| Flange and Shaft Option | Half-key balancing, IP 64, With Keyway |
| Manufacturer | Fagor Automation |
| Holding Brake Option | Without holding brake |
| Fan and Inertia Option | Standard |
| Winding Option | Standard |
| Temperature Sensor | RTD Pt1000 thermoresistence |
