DMS 5 Axis CNC Router E740 [SOLD]

Used 5 Axis CNC router, DMS, 5×12 table, 6th axis lathe, 48 in Z axis stroke, 11 hp HSD ATC spindle, Fagor 8055-M CNC.

Used 5 Axis DMS CNC router for sale, equipped with a stationary 5 ft x 12 ft aluminum table, 6th axis lathe, 48 inches of Z axis stroke, 11 hp HSD A.T.C. spindle and automatic tool change carousel. This used 5 axis DMS CNC router is controlled by Fagor Automation 8055-M CNC system.

Used 5 Axis CNC Router Specifications

  • DMS 5 axis CNC router model No.: 5B5-5-18-48-SCOLXX
  • Originally manufactured in 2008
  • 5′ x 12′ stationary aluminum router table
    • 3/8″ threaded inserts on 12″ centers
  • Heavy duty lathe 6th axis, removable
  • 72″ vertical bridge clearance
  • 48″ Z axis stroke
  • 11 hp HSD ATC spindle motor – ISO 30, 20,000 Max RPM
  • 12 position tool change carousel
  • Fagor 8055M CNC system controller
    • Tool center point compensation
    • Turbo card
  • Auto lube system
  • Auto tool height sensor
  • 230 V / 3 phase electrical requirements
  • 60 Amps / 60 Hz
  • 90PSI, 5CFM air requirement
  • CNC Machine is 18 ft. long
  • Z axis utilizes 32mm servo driven lead screw mounted with angular bearings
  • 35mm profiled ways on all linear axis
  • B Axis uses cycloidal 210:1 gearhead
  • C Axis uses cycloidal 109:1 gearhead
  • Speeds:
    • X-Axis – 1200 in./min.
    • Y Axis – 1200 in./min.
    • Z Axis – 600 in./min.
    • C Axis – 125 degrees/second
    • B Axis – 125 degrees/second
